Filtration type: Softening
Type: For hot water
Housing type: monoblock (“cabinet”)
Capacity, m3/h: 1.2
Dimensions (w/w/d) mm: 280 x 591 x 438 (WxHxL)
Weight (without surround) kg. 22,7
Mains power: 230 V/50 Hz
Charging volume, l: 12
Salt tank capacity, kg. 17
Water treatment: hardness salts, iron
Automatic control valve (flow-based)
Operating temperature, oC: 2-65
Working pressure: atm: 1.4 – 8.3
Water consumption for 1 regeneration, m3: 0.07
Salt consumption for 1 regeneration, l: 1,2
Connector diameter “: 3/4″ male thread BSP
SET CONTAINS
Housing, pcs: 1;
Control valve, pcs: 1;
Integrated bypass, pcs: 1;
Hose for connection to sewer, pcs: 1;
Filter cartridge, l: 12.
BENEFITS OF THE FILTER
Always keep the salt tank dry. The salt solution is prepared just before regeneration;
Built-in mixing bypass valve (mixing mode) for adjusting the water softening level;
Compact body made of high quality polyethylene;
Low salt signal in the tank;
Saves water consumption for filter regeneration;
A reminder to carry out filter maintenance;
Automatic shutdown of the water outlet during regeneration in case of power failure;
High water softening efficiency with Lewatit’s high ion exchange capacity cation;
The unique Eri 541N89 multi-functional control valve (single line LCD display) with display allows automatic control of the water softener and sets the regeneration frequency according to the water consumption, the convenient time of day and the maximum load.
Long lifetime of the filter material – up to 7 years.
How it works
The raw water passes through a Dowex cation exchange resin filter. After a certain level of contamination, the filter is cleaned by an automatic regeneration process controlled by a control valve.
Regeneration
Dowex resin used as a filtration medium is regenerable, i.e. it can be restored to its original properties. This process shall be carried out periodically when a defined contamination limit is reached. Regeneration takes place in several steps, the most important of which is the rinsing of the filter media with an aqueous salt solution. The salt is in the form of tablets, supplied in 25 kg bags. The regeneration process is automatic, thanks to a control valve with a digital controller.
AutomationThe filter is equipped with an electronic control valve that ensures fully automatic and cost-effective operation of the treatment system.
Advantages of an automatic control valve:Fully automatic operation
Monitoring the system based on the amount of treated water
Digital LCD display
Touch-sensitive flow sensor
Safe and cost-effective electronics, 24 V power supply
Built-in surge protection
All parts in contact with water are made of eco-friendly plastic
Electronic controller allows economical use of salt and water for system regeneration
Wide range of system programming options
In addition to the basic system settings, the controller has the following additional functions and statistical data collection options:
– Determining the water flow through the system
– Determining daily water consumption
– Setting the average daily water consumption
– Recommendations for installation and use
To protect the filter from mechanical impurities and to increase efficiency, it is recommended to install a mechanical filter upstream of the filter.
FURTHER INFORMATION:The water inlet pressure shall be at least 2 atm.
Air temperature: at least 2 °C .
